9−1−8.

Absolute value output

When net weight is selected for output data, output can be applied even to the (−) side of

display depending on the A−SEL signal condition on the rear panel terminal board by setting

“1” on FUNC−19.

Section of absolute value output

A−SEL

Short

Open

(＋

＋＋

＋)

(−

−−

−)

A/Z

Low

High

Display

Analog

output
