110
9−4. RS−422 Interface
Warning ● By feeding ON the instrument with external HOLD signal shorted ,
the output of RS−422 Interface will be as follows:
1
Even when the Display is targeted for HOLD with the FUNC−50,
the load weighing data will become only spaces at the time of
reading−out command for load weighing data is executed.
2
When the option is targeted for HOLD with the FUNC−50, the
load weighing data will become all spaces at the time of
reading−out command for load weighing data is executed.
3
Other than the case above ① and ②, selected load value will be
outputted.
● When the CHECK switch is applied, pay attention to the following
points.
1
By ON operation of CHECK, the instrument isn’t in Measurement
mode anymore (RUN display puts off, RUN output is open.),
however, RS−422 Interface responses to the command from the
host at the same time.
2
By ON operation of CHECK, “OL” error display might be shown.
At the same time when load weighing reading command is
executed, “OL” will be transferred to the host.
9−4−1.
Related functions
FUNC−30 Selection of baud rate 600, 1 200, 2 400, 4 800, 9 600, 19 200 bps
FUNC−31
Setting data bit length and
parity
Parity bit : NON, Even number parity,
Odd number parity bit
Data length : 8 bits, 7 bits
FUNC−32 Setting stop bit 1 bit, 2 bits
FUNC−33 Setting ID number 0 to 9
FUNC−34
Setting decimal point for
transferring code.
Yes, or No,
● Setting of this function becomes effective when power is ON.
After change has been made, put the power OFF.
● Through RS−422 Interface, FUNC−29 and Stream mode can’t be
used. Only Command mode is used.
