2. CNC Monitor Screen
2.5 Program
I - 129
[Copying words]
The word where the curso
r is placed can be copied t
o the <EDIT BUFFER>.
(1)
Search the word to be copid.
[
→
][
←
][
↑
][
↓
]
[BACK][NEXT]
(2)
Press the menu [COPY].
(a)
The word where the cursor is place is set
to <EDIT BUFFER>.
(b)
The cursor moves to the next word.
(Note 1)
"%" will not be copied.
