2. CNC Monitor Screen
2.5 Program
I - 134
Sequence No./block No. search
Sequence No. or block No. can be searched when only sequence No. or sequence No. and block No. is
entered without entering O No.
(1) Press the menu [COM.SRH].
The setting area for "COM.SRH" will be
displayed.
O( ) N( )-( )
COM.SRH
(2) Enter the sequence No. to be searched.
(Example)
O( ) N( 15)
－
( )
O( ) N( 15)-( )
COM.SRH
(3) Press [INPUT].
(a) Start the search.
(b) The program is displayed if the sequence
No. or block No. is found, and goes back
to the word edit screen (the first menu).
SEARCH EXECUTION
O( ) N( 15)-( )
COM.SRH
(Note 1) If the designated sequence No. is not found at the editing cursor position or below the executed
block, the message "E13 NB NOT FOUND" will be displayed.
When [INPUT] is pressed again, the designated sequence No. or block No. will be searched
from the head of the program.
