2. CNC Monitor Screen
2.7 Diagnosis
I - 200
# Item Details
Setting
range
32 E-CONDITION
Select the condition for ending the sampling process.
0: Sampling completed
Sampling ends upon buffer full when "one-shot" is selected in "#31
PROCESS FORM".
1: Variable No.
Sampling ends when "#33 VARIABLE No." is set to "0" (or null) value in
a machining program.
2: PLC device start
Sampling ends when the signal set in "#34 PLC DEVICE" is turned OFF.
(Note 1) When "1" is set
• Not the variable value itself but "setting the variable to 0 (or null) value
in a program" works as a trigger. Therefore, setting a variable value on
COMMON VARIABLE screen or with the PLC window does not work
as an end trigger.
• "Setting the variable to non-0 (nor null) value in a program" is canceled
(the end trigger is turned ON) by turning ON the reset (RST2/RRW)
which initialize the modal or SA signal.
• If a calculation is used for setting a common variable, which is a
floating point data, the result "0" may not be recognized due to the
calculation error.
• In multi-part system, an end trigger will not be turned ON until all part
systems meet the conditions.
(Note 2) Setting "0" for the end condition is invalid unless one-shot is
selected for "#31 PROCESS FORM". (The sampling does not end at
buffer full).
(Continued to the next page)
0 to 4
