Appendix 6. Operation Messages on Setting Display Unit
Appendix 6.1 Operation Errors
IV - 28
Error No. Error message Details
E86 INPUT DATA ERR
×
• When inputting the tool offset data‚ the data format was not
correct‚ so that block could not be input.
If the input key is pressed again in the input screen‚ the input
will continue from the next block.
• When data is read from parameter tape, its format is incorrect.
E87 NOT EDIT PROG.
×
• Playback edit was executed for a fixed cycle subprogram.
Playback edit of a fixed cycle subprogram is not possible.
E88 CAN’T ADD
BLOCK
×
• Playback edit cannot be executed unless the block being edited
with playback is displayed to the end (EOB) on the left side of
the machining program display area. Press the cursor key [ ↓ ]‚
and display the whole block to the end. Then‚ input the data.
E91 MODE ERROR
(PBK)
×
• G90 was set when "PLAYBACK G90" was off.
• G91 was set when "PLAYBACK G90" was on.
E110 ATA NOT READY
Δ
• ATA not mounted error when that appears when ATA Card
screen is opened
Mount the ATA card.
E111 FILE DUPLICATE
Δ
• The name of the file to be output was found in the ATA card.
• New file name to be renamed already exists.
E112 ATA I/F ERROR
×
• The designated file is damaged or the ATA card is damaged.
Designate another file or replace the ATA card.
E113 MEMORY OVER
×
• The ATA card capacity was filled when outputting to the ATA
card.
Delete files from the ATA card, or use another ATA card and
output the data again.
E114 CAN'T ERASE
×
• A directory containing subdirectories or files was required to be
deleted.
Delete the file and all subdirectories before deleting the
directory.
E115 FILE NOT FOUND
Δ
• The file to be input, compared, deleted or renamed was not
found in the ATA card.
Designate a file saved in the ATA card.
E117 DIR NOT FOUND
×
• The set directory was not found on the disk.
Check whether an intermediate directory was designated when
designating an absolute path.
E190 FORE EDITING
×
• An attempt was made to perform background search for the
program that is in foreground search status. (Word editing)
E191 NOT COM.
SEARCH
×
• Operation search was attempted in the tape mode.
E200 ADJUST ERROR
×
• The hardware status can’t be read correctly‚ so automatic
adjustment was not possible.
• Check the remote l/O unit.
• A Z55 RIO NOT CONNECT error occurred.
• Adjust manually.
• Unit defect (replace unit)
To Next Page
