MOOR INSTRUMENTS moorLDI2 RESEARCH USER MANUAL
126
22. SPECIFICATIONS
The moorLDI2 is a class IIa device under EC directive 93\42EEC 14 June 1993 Medical Device
Directive.
LASER SOURCE
moorLDI2-VR
moorLDI2-HR
Helium Neon Red Gas Laser: 633nm
(moorLDI2-VR) Accessible power 2.0mW - 2.5mW
(moorLDI2-HR) Accessible power 1.6mW – 1.8mW
Beam diameter (1/e
2
points) at 50cm from scanner window 1.2mm + 0.2mm (moorLDI2-VR)
Beam diameter (1/e
2
points) at 25cm from scanner window 0.1mm + 0.1mm (moorLDI2-HR)
Beam divergence 1.4 + 0.2milliradians
Ocular Hazard Distance 25m.
All measurements include cumulative measurement uncertainties and expected increases after
manufacture.
Class 3R per IEC 60825-1:2007 and complies with 21 CFR 1040.10 and 1040.11 except for
deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
moorLDI2-IR
moorLDI2-HIR
Infra-Red Laser Diode: 785 + 10nm
(moorLDI2-IR) Accessible power 2.0mW - 2.5mW
(moorLDI2-HIR) Accessible power 1.3 - 1.5mW
Beam diameter (1/e
2
points) at 50cm from scanner window 1.2mm + 0.2mm (moorLDI2-IR)
Beam diameter (1/e
2
points) at 25cm from scanner window 0.1mm + 0.1mm (moorLDI2-HIR)
Beam divergence is 1.4 + 0.2milliradians
Ocular Hazard Distance 20m.
All measurements include cumulative measurement uncertainties and expected increases after
manufacture.
Class 3R per IEC 60825-1:2007 and complies with 21 CFR 1040.10 and 1040.11 except for
deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
Visible Laser Diode (target beam for infrared systems): 660nm
±
10nm
(moorLDI2-IR) Accessible power 30
µ
W to 200
µ
W.
(moorLDI2-HIR) Accessible power 30
µ
W to 200
µ
W.
Beam diameter (1/e
2
points) at 50cm from scanner window 1.2mm + 0.2mm
Beam divergence is 1.4
±
0.2milliradians
All measurements include cumulative measurement uncertainties and expected increases after
manufacture.
Class 1 per IEC 60825-1:2007 and complies with 21 CFR 1040.10 and 1040.11 except for deviations
pursuant to Laser Notice No. 50, dated June 24, 2007.
