安装 / 拆下刀具
MOUNTING/REMOVING TOOLS
将刀具从主轴上拆下 Removing a Tool from the Spindle
1) 将门联锁钥匙开关置于 [ 平常 ] 位置。 1) Set the door interlock key-switch in the [NORMAL]
position.
2) 将操作选择钥匙开关旋至
i
[ 可操作 ] 或
o
[ 可操作 / 编
辑 ]。
2) Turn the operation selection key-switch to
i
[ON] or
o
[PANEL/EDIT].
3) 如果通过从刀库至主轴转移刀具来拆下刀具，则用以下步骤
将待拆下的刀具调入主轴。如果直接从主轴上拆下工具，则
至步骤 4)
3) If removing a tool by transferring the tool from the magazine
to the spindle, call the tool to be removed to the spindle by
using the following procedure. If removing a tool directly
from the spindle, go to the step 4)
a) 显示‘PROGRAM (MDI)’屏幕。 a) Display the ‘ PROGRAM (MDI) ’ screen.
模式选择按钮
s
[MDI]
D 功能选择键
p
( 程序 )
Mode selection button
s
[MDI] (MDI)
D Function selection key
p
(PROG)
b) 将每个轴返回至刀具更换位置。 b) Return each axis to the tool change position.
“ G91 G28 Z0 M05;
G28 X0 Y0 B0;
G30 X0 Y0 Z0; ”
D
i
( 插入 ) 键 D 自动运行按钮
q
[ 开始 ]
“ G91 G28 Z0 M05;
G28 X0 Y0 B0;
G30 X0 Y0 Z0;“
D
i
(INSERT) key D Automatic operation button
q
[START] (Start)
c) 将刀具调用至主轴。 c) Call the tool to the spindle.
“T（刀具编号） ; M06; ” D
i
( 插入 ) 键
D 自动运行按钮
q
[ 开始 ]
“ T (Tool number); M06;“ D
i
(INSERT) key
D Automatic operation button
q
[START] (Start)
4) 按下手动模式。 4) Press the manual mode.
5) 打开前门。 5) Open the front door.
6) 在加工室内用手握住刀具并按下 [ 刀具松开 ] 按钮。 6) Hold the tool with your hand and press the [Tool Unclamp]
button in the machining chamber.
[ 机床操作面板上的状态指示灯刀具夹紧熄灭。/ 刀具退出主
轴。]
[The status indicator TCL (tool clamp) on the machine
operation panel is extinguished./The tool comes out of the
spindle.]
7) 拆下刀具后，按下加工室中的 [ 刀具夹紧 ] 按钮。 7) After removing the tool, press the [Tool Clamp] button in
the machining chamber.
7 小心 7 CAUTION
手动将切削刀具从主轴上拆下时，在松开切削刀具时确保其
已正确支撑。同时也要小心不要将切削刀具落入机床中。
When removing a cutting tool from the spindle
manually, make sure that it is properly supported
before unclamping it. Also be careful not to drop the
cutting tool inside the machine.
[ 机床损坏 ] [Machine damage]
