mori seiki NMV5000 DCG - 设置参数屏幕; Setup Parameter Screen; 工件安装错误 屏幕; WORK SETTING ERROR Screen

功能选择键和显示屏幕
FUNCTION SELECTION KEYS AND DISPLAY SCREENS
196
当 MAPPS 参数 No. 1701 设置为“0”时，可用此功能。 This function can be used when MAPPS parameter No. 1701 is
set to “ 0 ”.
1) 按下 [>] 和 [T 参考 ] 显示会话式刀具文件列表。
[ 刀具文件列表显示在‘ 刀具注册 ’屏幕上。]
1) Press [>] and [T REFER] to display the conversational tool
file list.
[The tool file list is displayed on the ‘ TOOL
REGISTRATION ’ screen.]
2) 将光标移动到要注册的刀座编号处。 2) Move the cursor to the pot number to be registered.
3) 将光标移动到会话式刀具文件列表中的刀具类型处，并按下
[
(Enter) 键 /
\
( 输入 ) 键。
3) Move the cursor to a tool type in the conversational tool file
list and press the
[
(Enter) key/
\
(INPUT) key.
[ 显示所选刀具类型的会话式刀具列表（ T 参考列表）。] [The conversational tool list (T Refer List) of the selected
tool type is displayed.]
4) 将光标移动到要注册的刀具编号处，并按下
[
(Enter) 键 /
\
( 输入 ) 键。
4) Move the cursor to the tool number to be registered, and
press the
[
(Enter) key/
\
(INPUT) key.
[T 参考清单中的 T 代码设置为刀具编号。] [The T code in the T Refer List is set as a tool number.]
设置参数屏幕 Setup Parameter Screen
可在此屏幕上设定并显示设置参数。 The setup parameters can be set and displayed on this screen.
在此屏幕上，可以设置当显示‘ 刀具补偿 ’屏幕时光标所处位置。 On this screen, the position where the cursor is to be placed
can be set when the ‘ TOOL OFFSET ’ screen is displayed.
1) 将光标移动至‘ 自动光标随动 ’。 1) Move the cursor to ‘ CURSOR AUTO FOLLOWING ’.
2) 从下列中任选其一。 2) Select one from the following.
a) ‘ 无效 ’（默认值设置） a) ‘ INVALID ’ (default setting)
[ 在‘ 刀具补偿 ’屏幕上的光标位置将保持先前显示。] [The cursor position on the ‘ TOOL OFFSET ’ screen
that was previously displayed is retained.]
b) ‘ 有效 ’ b) ‘VALID’
[ 光标位于主轴刀具编号最右边三位数指示的偏移编号数
据（在‘ 磨损 ’栏‘ 刀具长度补偿 (H) ’下的框内）。]
[The cursor is located at the offset number data
indicated in the rightmost three digits of the spindle tool
number (the field in the ‘ WEAR ’ column under ‘ TL
LEN. OFFSET (H) ’).]
c) ‘ 有效 ’仅在手动和 MDI 模式下 c) ‘ VALID ’ in the manual and MDI modes only
[ 当选择任一模式时，光标位于主轴刀具编号最右边三位
数指示的偏移编号数据（在‘ 磨损 ’栏‘ 刀具长度补偿
(H) ’下的框内）。]
[When either mode is selected, the cursor is located at
the offset number data indicated in the rightmost three
digits of the spindle tool number (the field in the
‘ WEAR ’ column under ‘ TL LEN. OFFSET (H) ’).]
1 “ 参数设定 ” （ 96 页） 1 “PARAMETER SETTING” (page 96)
‘ 工件安装错误 ’屏幕 ‘ WORK SETTING ERROR ’ Screen
使用此功能，可以根据程序加工偏移的工件而无需更改程序。 With this function, a displaced workpiece can be machined
according to the program without changing the program.
也可以在 X、Y 和 Z 轴上设置旋转误差偏移数据。 It is also possible to set the offset data for rotation error on the
X-, Y-, and Z-axis.
2 注意 2 NOTE
此功能仅对 MSX-711IV 有效。 This function is valid only for MSX-711IV.
1) 使用光标选择要设定的轴。 1) Select the axis to be set using the cursor.
2) 测量各轴工件坐标系 X Y Z 和基于偏移后的工件的工件设定
坐标系 X' Y' Z' 之间的误差。用相同的步骤测量 X、Y 和 Z 轴
的旋转方向误差， a、b 和 c。
2) Measure the error between workpiece coordinate system X
Y Z and the workpiece setting coordinate system X' Y' Z'
that is based on the displaced workpiece for each axis.
Measure the rotation direction error on the X-, Y-, and
Z-axis, a, b and c, using the same procedure.
功能选择键
o
( 补偿 ) D [<] D [ 调试参数 ]
Function selection key
o
(OFFSET) D [<] D [SETUP
PARAM.]
功能选择键
o
( 补偿 ) D [<] D [ 工件安装错误 ]
Function selection key
o
(OFFSET) D [<] D [WORK SET
ER]
