197
功能选择键和显示屏幕
FUNCTION SELECTION KEYS AND DISPLAY SCREENS
2 注意 2 NOTE
屏幕上的“a”、“b”和 “c”意指在 X、Y 和 Z 轴上旋转方向误差。它
们不是用于附加轴 A、B 和 C。
“ a ” , “ b ” and “ c ” on the screen means the rotation direction error
on the X, Y, and Z axis. They are not for the additional axes A, B
and C.
X
X'
Y
Y'
y
Δ
Δ
x
-Δ
C°
Correct workpiece position
Displaced workpiece
Coordinate system X' Y' Z' (workpiece
setting coordinate system) based on the
displaced workpiece
Workpiece coordinate system X Y Z
Workpiece
正确的工件位置
偏移的工件
基于偏移的工件的坐标系 X' Y' Z'
（工件设定坐标系）
工件坐标系 X Y Z
工件
X
X
X
X'
X'
X'
Y
Y
Y
Y
Z
Z'
Z
Z
Z
Z'
Z'
Z'
Y'
Y'
Y'
Y'
Δ
c
Δ
a
X(=X')
Δ
b
(
Δx, Δy, Δz)
The workpiece coordinate system (X, Y, Z) is rotated
about the X-axis by Δa°
Futher rotated about the Y-axis by Δb°
Futher rotated about the Z-axis by Δc°
Workpiece setting coordinate system
工件坐标系 (X，Y，Z) 绕 X 轴旋转 Δa°
再绕 Y 轴旋转Δb°
再绕 Z 轴旋转Δc°
工件设定坐标系
