功能选择键和显示屏幕
FUNCTION SELECTION KEYS AND DISPLAY SCREENS
212
2 注意 2 NOTE
以下状态下，即使设置了计时器工作灯仍然打开。 Under the following conditions, the worklight remains ON even if the
timer is set.
• 数控电源打开后显示警告屏幕 • While a warning screen is displayed after the NC power is turned ON
• 释放门联锁时 • While the door interlock is released
<‘待机模式启动时间 1’、2 和 3> <‘ TIME TO BE IN POWER STANDBY 1 ’, 2 and 3>
当到达设置的“ 备用电源模式的时间 ”时，屏幕背景灯和机床内
工作灯关闭。
When the setting for “ time to be in power standby mode ” is
reached, the screen backlight and the in-machine worklight are
turned OFF.
< 取消备用电源模式 > <Canceling the Power Standby Mode>
通过执行下列任一操作取消备用电源模式： The power standby mode is canceled by performing any of the
following operations:
• 在数控操作面板、机床操作面板和选项面板上按下 / 转动任
一按钮 / 开关
• Pressing/turning any of the buttons/switches on the NC
operation panel, the machine operation panel, and the option
panel
• 操作紧急停止按钮（停止 / 释放） • Operating the emergency stop button (Stop/Release)
• 操作把手开关 • Operating the handle switches
• 打开 / 关闭门 • Opening/closing the door
• 释放门联锁 • Releasing the door interlock
• 操作门联锁释放按钮 • Operating the door interlock release button
• 外部暂停和重新设置（除外部启动外） • External suspension and resetting (except external start)
2 注意 2 NOTE
1. 通过执行以上任一操作关闭‘ 屏幕关闭时间 ’或‘ 机内照明待机时
间 ’时，屏幕或机床内工作灯转回至打开。
1. The screen or the in-machine worklight is turned back ON when
the ‘ TIMER FOR TURNING MONITOR OFF ’ or the ‘ STANDBY
TIMER FOR WORKLIGHT ’ is turned off by performing any of the
operations above.
2. 按下自动运行按钮
q
[ 开始 ] 不能取消备用电源模式。 2. The power standby mode cannot be canceled by pressing the
automatic operation button
q
[START] (Start).
‘ 多计数器 ’屏幕（选项） ‘ MULTI COUNTER ’ Screen (Option)
多计数器用于管理刀具寿命及控制加工工件的数量。此屏幕上
的“ 多计数器 ”有一个总计数器和 20 个计数器。可以用这些计
数器计数以下值。
The multi counter is used for managing tool lives as well as to
control the number of machined workpieces. There are a total
counter and 20 counters for “ multi counter ” on this screen.
Using these counters, the following values can be counted.
总计数器： TOTAL COUNTER:
完工工件总数 Total number of finished workpieces
多计数器： MULTI COUNTER:
当前值、预测值和设置值 CURRENT, PREDICT and SETTING values
1 “ 多计数器显示（选项） ” （ 247 页） 1 “Multi Counter Display (Option)” (page 247)
‘ 设定 ’屏幕 ‘ SETTING ’ Screen
此屏幕设置用于改变 MAPPS 和数控参数“ 有效 ”或“ 无效 ”状态
，也可以用于设置输入装置、磁带格式、验证停止、I/O 通道和
指定 M198 时用于输入 / 输出数控系统数据或调用子程序的装
置。
This screen is used to set the “ valid ” or “ invalid ” status for
changing the MAPPS and NC parameters and also for setting
the input unit, tape format, verification stop, I/O channel and
device to be used for inputting/outputting NC system data or
calling a sub-program when M198 is specified.
< 验证停止（选项） > <Verification Stop (Option)>
如果程序和序号是指定用于验证停止功能的，则在执行程序和
序号指定的程序块后，会建立一个单个程序块停止状态。
If program and sequence numbers are specified for the
verification stop function, a single block stop state is
established after executing the block identified by the specified
program and sequence numbers.
功能选择键
s
( 设定 ) D [ 定时器计数器 ] D [ 多计数器 ]
Function selection key
s
(SETTING) D [TIMER
COUNTER] D [MULTI- COUNTER]
功能选择键
s
( 设定 ) D [ 参数 ] D [ 设定 ]
Function selection key
s
(SETTING) D [PARAM.] D
[SETTING]
To Next Page
