功能选择键和显示屏幕
FUNCTION SELECTION KEYS AND DISPLAY SCREENS
210
2 注意 2 NOTE
当零点调整后建立了当前位置时，零点调整设置自动从“ 有效 ”变回
为“ 无效 ”。
When the present position is established after the adjustment of the
zero point, the setting for Zero Point Adjustment is automatically
returned from “ valid ” to “ invalid ”.
‘ATC MANUAL OPERATION’屏幕 ‘ ATC MANUAL OPERATION ’ Screen
此屏幕用于检查 ATC 状态及手动操作 ATC。 This screen is used to check the ATC status as well as to
operate the ATC manually.
2 注意 2 NOTE
屏幕右侧的高亮显示指示 ATC 处于该状态。 The highlighted display on the right side of the screen indicates that the
ATC is in the status.
1 单独手册，保养手册“ATC恢复操作 ” 1 Separate volume, MAINTENANCE MANUAL “ ATC Recovery
Operation ”
‘APC 手动操作 ’屏幕（选项） ‘ APC MANUAL OPERATION ’ Screen (Option)
此屏幕用于检查 APC 状态及手动操作 APC。 This screen is used to check the APC status as well as to
operate the APC manually.
2 注意 2 NOTE
屏幕右侧的高亮显示指示 APC 处于该状态。 The highlighted display on the right side of the screen indicates that the
APC is in the status.
1 “ 工作台交换机构使用说明书 ”，单独提供。 1 “ PALLET CHANGER INSTRUCTION MANUAL ”, separately
supplied.
‘AWC MANUAL OPERATION’屏幕（选项） ‘ AWC MANUAL OPERATION ’ Screen (Option)
此屏幕用于检查 AWC 状态及手动操作 AWC。 This screen is used to check the AWC status as well as to
operate the AWC manually.
1 单独手册“ 工件交换装置使用说明书 ” 1 Separate volume, “ WORKPIECE CHANGER INSTRUCTION
MANUAL ”
‘ 程序段删除 ’屏幕（选项） ‘ BLOCK DELETE ’ Screen (Option)
此屏幕用于设置块删除功能的有效 / 无效。 This screen is used to set valid/invalid for the block delete
function.
‘ 运行模式 ’屏幕 ‘ OPERATION MODE ’ Screen
此屏幕用于选择 DNC 模式 /MAPPS-DNC。 This screen is used to select DNC MODE/MAPPS-DNC.
1 参见 “ 卡 DNC 操作（使用用户存储区操作） ” （ 238 页） 1 Refer to “CARD DNC OPERATION (OPERATION USING USER
MEMORY AREA)” (page 238)
功能选择键
s
( 设定 ) D [ 操作面板 ] D [ATC MANU.OPE.]
Function selection key
s
(SETTING) D [OPE. PANEL] D
[ATC MANU.OPE.]
功能选择键
s
( 设定 ) D [ 操作面板 ] D [APC 操作手册 ]
Function selection key
s
(SETTING) D [OPE. PANEL] D
[APC MANU.OPE]
功能选择键
s
(设定) D [操作面板] D [AWC MANU. OPE.]
Function selection key
s
(SETTING) D [OPE. PANEL] D
[AWC MANU. OPE.]
功能选择键
s
( 设定 ) D [ 块删除 ]
Function selection key
s
(SETTING) D [BLOCK DEL.]
功能选择键
s
( 设定 ) D [ 操作面板 ] D [ 运行模式 ]
Function selection key
s
(SETTING) D [OPE. PANEL] D
[OPE. MODE]
