安全防护装置
SAFETY DEVICES
8
6.
如果保护盖或安全防护装置损坏，请致电森精机服务部。 6. If protective covers or safety devices are damaged,
contact the Mori Seiki Service Department.
2 注意 2 NOTE
根据机床型号的不同，各设备或装置的形状和位置可能有所不同。该图
表示 NMV5000 DCG。
The shape and location of each device or unit may differ depending on
the machine model. The figure shows the NMV5000 DCG.
[EMERGENCY STOP]
(Emergency Stop) Button
Door Lock Device
Coin Lock Key
Coin Lock Lever
[EMERGENCY STOP]
( 紧急停止 ) 按钮
门锁装置
硬币锁钥匙
硬币锁杆
