4-1
• In this Section
• Onboard Diagnostics
• Absolute Floor Encoding
• Registering Car Calls
•Test Mode
• Running on Test/Normal
• Final Adjustments on Test
• Final Adjustments on IND
• Final Adjustments on Normal
• Release to Normal Operation
In this Section
Before the car can be released to normal operation, final adjustments and code-mandated test-
ing must be completed and approved. At this point, all of the steps in Section 3 should have
been completed. Please read Section 5 before proceeding: it explains the adjustment and trou-
bleshooting tools available. This section describes:
• Diagnostics on the PC boards: Information about diagnostic messages and status
LEDs on the PC boards (see page 4-2).
• Absolute Floor Encoding: A description of car behavior with and without LS-QUTE
absolute floor encoding (see page 4-2).
• Registering Car Calls: How to register car calls (see page 4-3).
• Test Mode: A description of car behavior on Text Mode (see page 4-4).
• Running on Test/Normal: Instructions for beginning operation on Test and Normal
modes (see page 4-5).
• Final Adjustments on Test Mode: Instructions for making final adjustments (see
page 4-6).
• Final Adjustments on Independent Service: Instructions for making final adjust-
ments on Independent Service (see page 4-7).
• Final Adjustments on Normal Operation: Instructions for making final adjustments
on Normal Operation (see page 4-8).
• Release to Normal Operation: Final checks before releasing the elevator to normal
operation (see page 4-10).
