Appendix
7-18 Manual # 42-02-1P21
COP-2 Board #5 - ID: 5
The fifth COP-2 board contains standard dedicated car calls (see note) as follows:
COP-2 Board #6 - ID: 6
The sixth COP-2 board contains spare inputs as follows:
The sixth COP-2 board contains spare outputs as follows:
Note that the rear car calls stack on each other. For example, if a car serves floors 1 through 3,
does not serve floor 4, but does serve floors above 4, floors above floor 4 will move down one
connection rather than leave an I/O open.
IO8IO7IO6IO5IO4IO3IO2IO1
116R 115R 114R 113R 112R 111R 110R 109R
IO16 IO15 IO14 IO13 IO12 IO11 IO10 IO9
124R 123R 122R 121R 120R 119R 118R 117R
IO24 IO23 IO22 IO21 IO20 IO19 IO18 IO17
132R 131R 130R 129R 128R 127R 126R 125R
IO8IO7IO6IO5IO4IO3IO2IO1
- SPIN SPIN SPIN SPIN SPIN SPIN SPIN
IO16 IO15 IO14 IO13 IO12 IO11 IO10 IO9
SPOUTSPOUTSPOUTSPOUT----
IO24 IO23 IO22 IO21 IO20 IO19 IO18 IO17
-----SPOUTSPOUTSPOUT
