F5: Controller Utilities/Monitoring and Reporting
Place the F5 switch in the Up position (all others down). This
option provides access to the Controller Utilities Menu and the
Monitoring and Reporting Menu.
Controller Utilities Menu
Use this menu to register front and/or rear car calls, set the controller’s date and time, view and
clear the event log, and view system CAN bus and CTL diagnostic data. If Controller Utilities
Menu is not displayed, press N push button. Please refer to Figure 5.3.
Figure 5.3 Controller Utilities Menu
Registering Front or Rear Car Calls
1. Press S push button. Front Call Registration is displayed. Press S to select or press N
until Rear Call Registration is displayed and press S to select. Refer to Figure 5.3.
2. Press +/- push buttons to increment or decrement floor numbers.
3. Press and momentarily hold S push button to register calls: displays [ON] while held.
4. Press + and N push buttons together to back out of the current display.
FUNCTION SWITCHES
F8 F7 F6 F5 F4 F3 F2 F1
Controller Utilities Menu
* CONTROLLER *
*UTILITIES MENU*
- FRONT CALL -
- REGISTRATION -
FRONT CAR CALL
LANDING 01 [OFF]
S
S
- REAR CALL -
- REGISTRATION -
N
FRONT CAR CALL
LANDING 02 [OFF]
+/-
+/-
FRONT CAR CALL
LANDING 02 [ON]
S*
REAR CAR CALL
LANDING 01 [OFF]
S
TIME: 02:35:10
DATE: 02-08-2010
TIME: 02:35:10
DATE: 02-08-2010
S
REAR CAR CALL
LANDING 02 [OFF]
+/-
+/-
REAR CAR CALL
LANDING 02 [ON]
S*
+ and N
+
and
N
+
and
N
+
and
N
+
and
N
+
and
N
+
and
N
+
and
N
+ and N
+ and N
SAVE DATE/TIME?
[S]-YES [N]-NO
N
+ and N
+ and N + and N
+ and N
S
S
+/-
+ and N + and N
+ and N
N
N
- VIEW -
- DATE AND TIME-
N
- ADJUST -
- DATE AND TIME-
N
- VIEW -
- EVENT LOG -
N
- CLEAR -
- EVENT LOG -
-SYSTEM CAN BUS-
- DATA VIEWING -
TIME: 02:40:00
DATE: 02-08-2010
S
+ and N + and N
EVENT LOG
CLEARED
#01 DOL INPUT FA
C01 05/25/2010
S
+ and N
Scrolling message
CID| 00 00 00 00
1C1| 0A 01 00 01
S
+ and N
CAN data bytes in hex
CLEAR ALL EVENTS
[S]-YES [N]-NO
