Motion 2000 TSSA Description
1-20 Manual # 42-02-1P21
Monitoring and Control Options
Motion 2000 is Ethernet ready, allowing it to use iMonitor and iReport applications for local
and/or distance monitoring and control (iMonitor) or report generation, archival, and auto-
mated alert (iReport). Motion 2000 can also be linked to Building Management System soft-
ware through MCE BMS-Link, providing system visibility and limited control.
iMonitor
iMonitor is an elevator monitoring application that allows local or remote viewing and control
of MCE elevator groups using a personal computer running the Windows XP operating system.
Because Motion 2000 controls are Ethernet capable, you can connect to them though a local
area network or remotely through internet/modem technology.
iMonitor provides a graphical representation of elevator groups, allowing their activity and sta-
tus to be quickly and easily viewed. The user defines any number of “Connection Sets.” Each
Connection Set consists of up to fifty connections to elevator group dispatchers selected by the
user.
When working in iMonitor, the user simply clicks on a Connection Set which automatically
establishes communication with all groups in the set and displays their associated hoistways
and cars on the computer screen. Practical viewing limits are established by the speed of the
connections and the size of the monitor viewing area.
When connected through iMonitor, the user may register car and general, auxiliary, or special
hall calls as desired, control many group security functions, and enable or disable certain eleva-
tor operating modes.
iReport
iReport is a system logging and report generating tool that allows local or remote analysis of
MCE elevator groups from a personal computer running the Windows XP operating system and
iReport client software. Because Motion 2000 controls are Ethernet capable, you can use iRe-
port to connect to them through a local area network or remotely through internet/modem
technology.
iReport consists of the iReport server and iReport clients. Motion 2000 group dispatchers may
be connected to iReport directly through a local area network or they may be connected
remotely through a DSL or other high-speed connection and the internet. The group dispatcher
provides iReport with hall call and car operating mode information. The individual car control-
lers provide iReport with event and fault notifications.
