Motion Control Engineering 2000 User Manual

PC Board Quick References
6-37
6
PC Board Quick References
This section contains information about Motion 2000 circuit boards including photographs
with informational call outs, input/outputs, indicators, jumpers, test points and other informa-
tion pertinent to troubleshooting.
The circuit boards are listed in the table below. If you are viewing this file on a computer, click
the page number to jump to the appropriate section.
Table 6.2 Motion 2000 Circuit Boards
Board Name See
HC-CHP CAN Hub and Power Supply Board page 6-38
HC-CTL-2 Control Board page 6-40
HC-DVR Driver Board page 6-47
HC-MPU Main Processor Unit Board page 6-50
HC-UIO-2 Universal Input/Output Board page 6-53
ICE-COP-2 Car panel interface board page 6-60
MC-CPI Car Panel Interface Board page 6-60
MC-LSI Landing System Interface Board page 6-67
SC-3HN Serial Hall Call Node Board page 6-70
