Motion Control Engineering 2000 User Manual

The Computer
5-16 Manual # 42-02-1P21
Step-by-Step Example
The table provides a step-by-step example of using Program mode. In this example, the Fire
Phase I Alternate floor will be changed. Similar steps can be taken to change any option.
Table 5.5 Using the Program Mode
Steps to take Display menus and sub-menus
Put the car on Inspection
D INSPECTION OPE
PI 8 20:1O11OOOO
Flip F1 switch Up
PROGRAM MODE
PRESS N TO BEGIN
Press N button for Next
*BASIC FEATURES*
* MENU *
Press N button for Next
* FIRE SERVICE *
* MENU *
Press S button to Select
FIRE SERVICE
OPERATION? YES
Press N button for Next
FIRE PHASE 1
MAIN FLOOR = 1
Press N button for Next
FIRE PHASE 1
ALT. FLOOR = 1
Press S button to select next available
value. If you pass the desired value,
press S until the desired value appears
again.
FIRE SVCE. CODE
ALT.FLOOR = 3
Press N button for Next
FIRE SVCE. CODE
xxxx
Press N button for Next
BYPASS STOP SW.
ON PHASE 1? YES
Press N button to scroll through any remaining Fire Service sub-menus.
Press N button for Next
* FIRE SERVICE *
* MENU *
Press N button for Next
*DOOR OPERATION*
* MENU *
Press N button for Next
* TIMER *
* MENU *
Press N button for Next
*GONGS/LANTERNS*
* MENU *
Press N button for Next
* SPARE INPUTS *
* MENU *
Press N button for Next
*SPARE OUTPUTS*
* MENU *
Press N button for Next
*EXTRA FEATURES*
* MENU *
Press N button for Next
*ADDITIONAL CAR*
* OPTIONS *
Press N
button for Next
* SAVE CHANGES?*
* N=NO S=YES *
Press S button to Save
PROGRAM MODE
PRESS N TO BEGIN
Flip F1 switch Down and take car off of
Inspection
The new options are stored and are now in
effect.
