Motion Control Engineering 2000 User Manual

Troubleshooting
6-44 Manual # 42-02-1P21
HC-CTL-2 Board LED Indicators
Indicator LEDs for board connections light when the corresponding input or output is active.
J27 FRSA Fire Service Alternate Initiating Device, machine room (input)
FRSM Fire Service Main Initiating Device, all other hoistway fire service initiating
devices (input)
FRES Fire Service Reset (input)
FRA Main Landing Smoke Sensor (input)
FRS Smoke/Fire Sensors for all landing that are not main (input)
INCT Car Top Inspection
CTEN Car top enable button input
ICTU Car top inspection Up button
ICTD Car top inspection Down button
ICEN In car inspection enable button input
INCP In car inspection switch input, INSP position
INN COP Access enable switch, NORM input
INA COP Access enable switch, ACC input
ATU Top access switch, Up position
ATD Top access switch, Down position
ABU Bottom access switch, Up position
ABD Bottom access switch, Down position
UETS Up emergency terminal switch input
DETS Down emergency terminal switch input
DCL Door close limit input
DOL Door open limit input
DPM Door position monitor switch input
PHE Photo eye, infrared detector input
IND Independent service switch input
DCB Door close button input
DOB Door open button input
CCB Fire service car call cancel button input
FCS Phase II Fire Service Operation On (On position, 3-position fire service switch)
HLD Phase II Fire Service Operation Hold (Hold position, 3-position fire service switch)
OFF Phase II Fire Service Operation Off (Off position, 3-position fire service switch)
FRON Fire Recall Operation On (input)
FSLL Fire Service Indicator for Lobby (output)
FSLC C.O.P. Fire Service Light (output)
FWI Fire Service Buzzer (output)
NBZ Nudging Buzzer (output)
NUDG Nudging enable output
DOF Door open function output, initiates door opening at landing
DCF Door close function output, initiates door closing at landing
DCP Door close power, enables door closing power application while car is running
Table 6.3 HC-CTL-2 Board Terminals
Connector Terminal Description
