Motion Control Engineering 2000 User Manual

PC Board Quick References
6-43
6
J15
MCE wired
at factory.
Not for field
connection.
1 Ground
DCOM Digital Common
2120 VAC
2MV Provides 120VAC to 2L bus when SAFL and SAFS relays are picked (input).
2L Provides 120VAC to valves and motor signals when doors are locked and safety
string is made up (Output).
J16
MCE wired
at factory.
Not for field
connection.
DZR See description, connector J12
DZF See description, connector J12
DLAT See description, connector J12
DLMS See description, connector J12
DLABR See description, connector J12
DCABR See description, connector J12
GSR See description, connector J12
J17 SPIN1 Programmable spare input #1. Defined on job prints if used.
SPIN2 Programmable spare input #2. Defined on job prints if used.
SPIN3 Programmable spare input #3. Defined on job prints if used.
SPIN4 Programmable spare input #4. Defined on job prints if used.
SPIN5 Programmable spare input #5. Defined on job prints if used.
SPIN6 Programmable spare input #6. Defined on job prints if used.
SPIN7 Programmable spare input #7. Defined on job prints if used.
SPIN8 Programmable spare input #8. Defined on job prints if used.
SPIN9 Programmable spare input #9. Defined on job prints if used.
SPIN10 Programmable spare input #10. Defined on job prints if used.
Table 6.3 HC-CTL-2 Board Terminals
Connector Terminal Description
