Motion Control Engineering 2000 User Manual

PC Board Quick References
6-41
6
HC-CTL-2 Terminal Definitions
Table 6.3 HC-CTL-2 Board Terminals
Connector Terminal Description
J1 Board programming, factory only
J2 Board programming, factory only
J3 Board programming, factory only
J4 CAN CAN bus connection from HC-CHP board
J5 DS Not used for traction control
DF Not used for traction control
US Not used for traction control
UF Not used for traction control
J6
MCE wired
at factory.
Not for field
connection.
BAB1 Bottom access
TAB1 Top access
ESC In-car stop switch bypass (completes SAFC safety string with switch open)
ABB1
SAFC Safety string, car
SAFH Safety string, hoistway
DCAT Door contact access top (top access floor door contact “made”)
DCMS Door contact middle string (floors between access floors, contacts “made”)
DLAB Door lock access bottom (bottom access floor door lock “made”)
DCAB Door contact access bottom (bottom access floor door contact “made”)
GS Gate switch (car gate switch “made”)
J7 CAN CAN bus connection, spare
J8
MCE wired
at factory.
Not for field
connection.
FCS See description, connector J27
CCB See description, connector J27
DOB See description, connector J27
DCB See description, connector J27
IND See description, connector J27
PHE See description, connector J27
DPM See description, connector J27
DOL See description, connector J27
DCL See description, connector J27
J9
MCE wired
at factory.
Not for field
connection.
DCP See description, connector J27
DCF See description, connector J27
DOF See description, connector J27
NUDG See description, connector J27
NBZ See description, connector J27
FWI See description, connector J27
FSLC See description, connector J27
FSLL See description, connector J27
FRON See description, connector J27
OFF See description, connector J27
HLD See description, connector J27
