F1: Program Mode
5-49
grammed before the car calls will cancel. To program this option, set PHOTO EYE ANTI-NUI-
SANCE? to NO or press S to select the number of consecutive stops. If S is pressed, the display
will read CONSEC STOPS W/O PHE LIMIT. Press S until the desired number is displayed.
DEDICATED CARD READER SECURITY? Enables card reader security through HC-
UIO boards set aside (dedicated) for security I/O only. No non-security I/O may be connected
to these boards.
UIO Board/Security Enforcement/Connection Order
The maximum number of security system signal connections for a single floor is four: One each
for front and rear control panels and one each for front and rear hall stations. In reality, each
floor may not require all four inputs; for example, some floors may not have rear doors while
others do. In order to use UIO board connections most efficiently, the system uses the floor ser-
vice “map” set up through Basic Features, page 5-18, and information from the following option
set of four prompts, to set aside the actual number of security connections required for each
floor. THESE OPTIONS ARE FACTORY-SET, if the information is available, before the
system is shipped and you just follow the job prints to make connections.
CARD REDR INPUTS- STACKED C/H? If No, the system knows that each security
UIO board’s connections will be of one type (hall reader or car panel reader). Press S to set to
NO. Press N to move to the next option.
• If yes, the system knows that car and hall security may be serviced by different connec-
tions on the same UIO board. It will then need clarification as to which calls must be
accommodated:
• After setting CARD REDR INPUTS - STACKED C/H to YES, use the + key to move to the
next “clarification” prompt.
• CARD REDR INPUTS - F CAR CALS? Y/N. Use the S key to respond. Yes if you have front
car call readers; No if you do not. Use the + key to move to the next prompt.
• CARD REDR INPUTS - F HAL CALS? Y/N. Use the S key to respond. Yes if you have front
hall call readers; No if you do not. Use the + key to move to the next prompt.
• CARD REDR INPUTS - R CAR CALS? Y/N. Use the S key to respond. Yes if you have rear
car call readers; No if you do not. Use the + key to move to the next prompt.
• CARD REDR INPUTS - R HAL CALS? Y/N. Use the S key to respond. Yes if you have rear
hall call readers; No if you do not.
• Press N to exit the prompt set.
IND. CNCL. CALLS ON STOP? If yes, on Independent service and if more than one
car call is registered, when the first car call is answered all other registered car calls will be can-
celed.
WPIx LANDING? (x = A thru H) Wandering Patient Security (Bracelet Security)
When a WPIx input is activated, hall calls to the landing and side associated with that input are
disabled. If the elevator is already at that landing with doors open, it will be shut down and pre-
vented from leaving that landing. Set the landing number and the side (Front, Rear or Both) to
be disabled when the corresponding spare input (WPIA thru WPIH) is activated.
ALLOW CAR CALLS ON WP SEC.? YES/NO - Wandering Patient Security (Bracelet
Security) If set to Yes, car calls to landings with active WPIx inputs are allowed, otherwise car
calls to those landings shall be disabled.
