The Computer
5-28 Manual # 42-02-1P21
SYNC. OP. DELAY TIMER (Range: None or 1 - 120 seconds) - If Synchronization
Operation has been requested via the SYNCI input (see “SYNCI” on page 5-38) or the Sync. Op.
Days timed feature (see “SYNC. OP. DAYS” on page 5-55), this timer will start when the car
becomes idle (no demand) and the doors are closed and locked. If Retiring Cam = Yes, the doors
would only need to be closed, not locked, before the timer starts. The timer must then expire
before the car will respond to the request for Synchronization Operation. If the door opens or
the car moves before the timer expires, the timer is reset and will begin again once the car is idle
with doors closed and locked.
Gongs/Lanterns Menu Options
MOUNTED IN HALL OR CAR? This option determines when the lanterns and gongs
will be activated, as the car slows into the floor for hall mounted fixtures or after the door lock
opens for car mounted fixtures. If both types of lanterns will be used, then the Hall option is
recommended.
DOUBLE STRIKE ON DOWN? This option causes a double strike of the lanterns and
gongs, if the direction preference of the car is down.
PFG ENABLE BUTTON? (Passing Floor Gong Enable Button) If this option is selected,
the Passing Floor Gong will only be operative when initiated by a momentary pressure pushbut-
ton. Once initiated, the Passing Floor Gong will operate for the current direction of travel but
will be rendered inoperative when the car reverses direction. The PFGE spare input (see “Spare
Inputs Menu Options” on page 5-29) should also be selected if this option is turned ON.
EGRESS FLOOR ARRIVAL GONG? / MAIN EGRESS FLOOR # To program this
option (Michigan Code), set one of the spare outputs to EFG. Then, set EGRESS FLOOR
ARRIVAL GONG? to NO (no gong) or press S to select the floor number where the gong should
activate (after the door lock opens). If S is pressed, the display will read MAIN EGRESS FLOOR
#1. Press S until the desired floor number is displayed.
CAR LANTERN DOOR FULLY OPEN If NO, the car lantern turns on when the doors
begin to open and remains on until the doors are fully closed. If YES, the car lantern turns on
when the doors are fully open and turn off when the doors begin to close.
