F1: Program Mode
5-55
SPEED > 150 FPM? (YES/NO) - This option must be set to YES on ASME A17.1-2000
code compliant hydraulic elevators with speeds exceeding 150 FPM. When on Inspection opera-
tion, running at high speed is prevented by disabling the FUD output.
DOOR POSITION MONITOR: (NONE/FRONT/REAR/BOTH) - This parameter indi-
cates the use of a door position monitor on front, rear or both doors (DPM / DPMR inputs) in
order to enable the door position monitor logic.
FRONT DOOR CLOSE LIMIT? (NONE/DCL/GS+DCAB) - Set to the front door close
limit signals used by this car. (DCL for door close limit switch. GS and DCAB for gate switch and
door closed bottom access. None.)
REAR DOOR CLOSE LIMIT? (NONE/DCL/GS+DCAB) - Set to the rear door close
limit signals used by this car. (DCL for door close limit switch. GS and DCAB for gate switch and
door closed bottom access. None.)
LS-EDGE LANDING SYSTEM? (YES/NO - Set to YES if you are using the LS-EDGE
landing system.
Timed Features
This menu allows you to select and program features that will be executed based on a time
schedule.
SYNC. OP. DAYS (EVERYDAY, MON, TUE, WED, THUR, FRI, SAT, SUN) - Use S and
+ push buttons to select (YES/NO) the day(s) on which the Synchronization operation is to be
performed (use in lieu of SYNCI input, see “SYNCI” on page 5-38).
SYNC. STARTING TIME (24 hour format / 30 minute increments) - Set the
time at which the Synchronization operation is to begin (see “SYNC. OP. DELAY
TIMER” on page 5-28).
