Appendix
7-2 Manual # 42-02-1P21
Motion 2000 Parameter Settings Record
This form is provided for recording the current parameter settings on your Motion 2000 con-
troller. If the firmware is upgraded or parameters are re-set to default values, you can then com-
pare the parameter settings to this record to verify that they are correct.
Job Number: __________________ Date: _________ Bootrom Ver#__________
Job Name: _______________________________________ Car Number: _____
Table 1. Firmware Versions (F8) and (F1 and F8)
Function
Switch
Processor Current Version New Version
F8 MPU B
R____
Ver# H___.___.______
R____
Ver# H__.__.____
F1 & F8 MPU A
F1 & F8 CTL A
F1 & F8 CTL B
F1 & F8 CTL C
F1 & F8 RDR A
F1 & F8 RDR B
F1 & F8 UIO
F1 & F8 CHP
F1 & F8 DVR
Table 2. Floor and Message Labels (F4)
Landing/
Msg #
Floor
Label
Msg
Label
Landing/
Msg #
Floor
Label
Msg
Label
Landing/
Msg #
Floor
Label
Msg
Label
Landing/
Msg #
Floor
Label
Msg
Label
01
11 21 31
02 12 22 32
03 13 23
04 14 24
05 15 25
06 16 26
07 17 27
08 18 28
09 19 29
10 20 30
