Final Adjustment
4-10 Manual # 42-02-1P21
Final Testing, LS-EDGE Only
This instruction provides a way to test the independent, hardware slowdown means at terminal
stops when the normal stepping slowdown means have been disabled in a Motion 2000 hydrau-
lic installation equipped with the MCE LS-EDGE landing system.
Bottom Terminal Test
1. Move car to an upper floor.
2. Place the car on Inspection mode.
3. Select F7 menu. After noting the current value, set STEP DN 1 to zero (0.0).
4. Save the setting. This effectively removes the step down.
5. Take the car off Inspection.
6. Through the F5 > CONTROLLER UTILITIES > FRONT CALL REGISTRATION/REAR
CALL REGISTRATION menu, place a call to a floor one or two stops above the bottom
terminal floor.
7. Once the car is stable at the floor, place a call to the first (bottom terminal) floor.
8. Monitor the car and note that it slows at the terminal due to the independent, built-in
hardware slowdown means.
Top Terminal Test
1. Place the car on Inspection mode.
2. Select F7 menu. After noting the current value, set STEP UP x for the top (terminal)
floor to zero (0.0).
3. Save the setting. This effectively removes the step up.
4. Take the car off Inspection.
5. Through the F5 > CONTROLLER UTILITIES > FRONT CALL REGISTRATION/REAR
CALL REGISTRATION menu, place a call to a floor one or two stops below the top (ter-
minal) floor.
6. Once the car is stable at the floor, place a call to the top (terminal) floor.
7. Monitor the car and note that it slows at the terminal due to the independent, built-in
hardware slowdown means.
Restore Original Settings
1. Place the car on Inspection mode.
2. Select the F7 menu.
3. Return STEP DN 1 to its original setting.
4. Return STEP UP x for the top (terminal) floor to its original setting.
5. Save the changed settings.
6. Return the car to Normal operation.
