Set Up for Construction Operation
3-5
• DNTD, UNTD: Up and down terminal limit switches. Connecting 2L bus to these termi-
nals clears the faults caused by the final limit terminals being open.
• USL1, USL2, DSL1, DSL2: Slow down limits. Connecting 2L bus to these terminals clears
the faults caused by having both sets of slow down terminals open.
• Custom Connections: Custom spare input connections that are active low and affect car
motion, such as the Pressure Switch and Low Oil Switch, must be installed.
Temporary Jumpers
Temporary jumpers, as necessary, may be connected if needed to run the car on construction /
inspection operation. For Temporary Run Box connections see page 3-6.
Resolving Faults
If the car does not respond to a run command, check the HC-MPU board for error/fault codes.
Please refer to “Status and Error Messages” on page 6-3. Error codes are displayed individually
in the order of detection. It is possible that, after you correct a current error condition, another
will be displayed. All errors must be resolved before the car will operate properly.
Table 3.1 Construction Mode Jumper Requirements
From To
2 bus SAFH on HC-CTL-2 board (Safety String, Hoistway)
SAFH on HC-CTL SAFC on HC-CTL-2 board (Safety String, Car)
SAFC on HC-CTL ESC on HC-CTL-2 board (In-car Emergency Switch)
2 bus (120VAC) GS on HC-CTL-2 board (Gate Switch, car door locks)
2 bus (120VAC) INN on HC-CTL-2 board
2 bus (120VAC) GSR on HC-CTL-2 board (Rear Gate Switch, car door locks)
2 bus (120VAC) DLAB on HC-CTL-2 board (Door Lock Access Bottom, hall doors)
2 bus (120VAC) DLABR on HC-CTL-2 board (Rear Door Lock Access Bottom, hall doors)
2 bus (120VAC) DPM on HC-CTL-2 board or HC-UIO board (Door Position Monitor)
2 bus (120VAC) DPMR on HC-CTL-2 board or HC-UIO board (Door Position Monitor Rear)
TO1 on HC-DVR TO2 on HC-DVR board or install thermal overload as specified on job prints
2L bus (120VAC) DNTD and UNTD on HC-DVR board (Normal Terminal inputs)
2L bus (120VAC) USL1, USL2, DSL1, DSL2 (Slow down limits) to clear faults. Must be installed to run the
high speed valves while on Construction Mode. However. if the car’s contract speed is
greater than 150fpm, set HIGH SPEED INSPECTION option to DISABLED (see page 5-66).
2FS bus
(120VAC)
FRS, FRSA, and FRSM on HC-CTL-2 board (Fire Service inputs) only required to clear
faults. Car will run on Inspection without the jumpers.
