F1: Program Mode
5-17
Basic Feature Menu Options
CONTROLLER TYPE: (HYDRO (M2000)/TRACTION (M4000)) Determines the firm-
ware that will be used for this controller. This parameter should have been factory set based on
the type of controller in use, hydro or traction.
SIMPLEX / LOCAL OR DUPLEX? The controller has been programmed at the fac-
tory for either simplex, local or duplex capability.
If the controller has simplex capability, it can only operate a single car as a simplex.
This parameter should be set to LOCAL if the car is part of a group connected to a group dis-
patcher.
If the controller has duplex capability, then it can operate a single car as a simplex, or it can be
connected to a second Motion 2000 controller and the 2 controllers can operate 2 cars as a
duplex.
Both Motion 2000 controllers must have duplex capability for this arrangement to work. Also,
the Simplex/Duplex option on each controller must be set to duplex.
In Duplex configuration, one of the controllers will assert itself as the dispatcher and will
remain the dispatcher unless it is taken offline. The dispatching controller will show a “D” on its
LCD; the other, an “S.” Hall calls are physically connected to both controllers
OPERATION: Dispatching operation - For simplex operation, there are 3 dispatching
operations to choose from: Selective Collective, Single Button Collective, or Single Automatic
Push button. Each operation is described below:
•
Selective Collective - Choose this operation if there is an UP and DOWN button at each
landing station except for the top floor (DOWN button only) and bottom floor (UP button
only) and any number of calls can be registered at one time.
•
Single Button Collective - Choose this operation if there is only 1 call button at each
landing station and any number of calls can be registered at one time.
•
Single Automatic Push button - Choose this operation if there is only 1 call button at
each landing station and only 1 call can be registered and/or serviced at a time.
If either Single Button Collective or Single Automatic Push button operation is selected, then
one of the spare output terminals should be used for an INDFRC output. This output is used to
disconnect the hall calls during Fire Service and Independent Service (see “Spare Outputs Menu
Options” on page 5-39, INDFRC output for more details). Refer to the Job Prints for informa-
tion on using the INDFRC output to disconnect hall calls.
For duplex operation, the dispatching scheme is always Selective Collective. Therefore, the
Operation option message will not appear on the display if the duplex option has been selected.
