The Computer
5-100 Manual # 42-02-1P21
F6: Hoistway Learn Operations
The F6 menu provides a process to learn the floor levels and counterweight position for the
building. The process is different depending on the type of landing/positioning system for the
job.
LS-EDGE Steel Tape
Please refer to “Hoistway Learn, LS-EDGE” on page 3-5.
Adjusting Floor Heights
Stored floor heights may be accessed through the F7 menu (first 64 parameters) and the height
of each floor individually adjusted at any time. F7 parameter 67 allows you to adjust the coun-
terweight height.
1. Enter the F7 menu (F7 up, all other switches down).
2. Press N to advance to the desired parameter.
3. Use “+” or “-” buttons to adjust the height of the floor (or counterweight).
4. Place F7 in the down position.
