Enhanced Page Turn Passbook Printer
How to Clear Jams
9-8 NCR Personas M Series 5887 Operator Manual
9 Attach the ribbon cartridge by threading the ribbon through the
ribbon guide of the print head carrier, then push the cartridge
down to its home position.
10 Push down the print head carrier to its home position.
11 Tighten the ribbon by turning the ribbon feed knob on the
ribbon cartridge in the direction of the arrow marked on the
cartridge.
12 Firmly push the print head carrier left and right several times to
make sure the ribbon does not come out of the ribbon guide.
13 Push the printer back into the terminal until it clicks into place.
14 Follow your in-house procedures for indicating that you have
fixed, without replacing, the passbook printer mechanism.
15 If you terminal does not have auto-supervisor, press the switch
on the operator panel to the normal position.
16 Close and lock the exterior of the ATM.
Ribbon Guide
Print Head
Ink Ribbon
Ribbon Feed
Knob
