For information about enabling and configuring the IPTV virtual interface, see one of the following sections:
• Manually Set Up an ADSL Internet Connection on page 41
• Manually Set Up a VDSL Internet Connection on page 51
• Manually Set Up a Cable Internet Connection on page 60
If your ISP provides directions for how to set up VLANs for IPTV and Internet service,
follow those directions.
Note
To enable and configure a VLAN for the Internet virtual interface and another VLAN for the
IPTV virtual interface:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select Internet.
5. Configure a VLAN for the Internet virtual interface:
a. Make sure that Internet is selected from the menu above the Enable This Interface check box and
that the Enable This Interface check box is selected for the Internet virtual interface (it is by default).
b. Select the Use VLANID check box.
c. Enter a VLAN ID that applies to the Internet virtual interface.
The VLAN ID can be in a range from 0 to 4094.The default VLAN ID is 10.
Manage the WAN and LAN Network Settings
174
AC1200 WiFi VDSL/ADSL Modem Router Model D6220
