NETGEAR D6220 User Manual

• Ethernet cable. Use an Ethernet cable to connect your computer to a yellow Ethernet LAN port on
the modem router.
The product package contains a yellow Ethernet cable.
Your computer connects to the modem router’s LAN.
• WiFi. Connect to the default WiFi network of the modem router:
a. On your WiFi-enabled computer or mobile device, find and select the WiFi network.
The WiFi network name (SSID) is on the product label.
b. Join the WiFi network and enter the WiFi password.
The password (network key) is on the product label.
Your WiFi-enabled computer or mobile device connects to the modem router’s WiFi network.
If the computer is set to a static (fixed) IP address (this setting is uncommon), either
change the computer to obtain an IP address automatically from the modem router
through DHCP, or change the IP address of the computer to a static IP address in
the 192.168.0.2–192.168.0.254 range.
Note
8. Launch a web browser.
The modem router checks the Internet connection.
If the Configuring the Internet Connection page displays, skip to Step 11. If the page does not display,
see Step 9.
Install and Access the Modem Router and Its Network
20
AC1200 WiFi VDSL/ADSL Modem Router Model D6220

NETGEAR D6220 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	900 Mbit/s
Product type	Tabletop router
Product color	Black
Security algorithms	WPA, WPA2, WPA2-PSK
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Power source type	AC
Routing protocols	IP
Antennas quantity	2
Cables included	LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	182 mm
Width	240 mm
Height	41 mm
Weight	341 g
