9. If the Configuring the Internet Connection page does not display, do the following:
a. In the address field of the web browser, enter www.routerlogin.net.
b. When prompted, enter admin for the user name and password for the password.
If the Configuring the Internet Connection page displays, skip to Step 11. If the page still does not display,
see Step 10.
10. If the browser cannot display the web page, do the following:
a. Make sure that the computer is connected to one of the four Ethernet LAN ports or over WiFi to the
modem router.
b.
Make sure that the Power LED of the modem router is lit solid green.
c. Make sure that your browser does not cache the previous page by closing and reopening the
browser.
d. Clear the browser cache.
e. If the computer is set to a static (fixed) IP address (this setting is uncommon), either change the
computer to obtain an IP address automatically from the modem router through DHCP, or change
the IP address of the computer to a static IP address in the 192.168.0.2–192.168.0.254 range.
11. From the Country menu, select the country in which you use the modem router.
12. From the Internet Service Provider menu, select the Internet service provider (ISP) that you are using.
If your ISP is not in the menu, select Other.
13. Select the Yes radio button.
14. Click the Next button.
Install and Access the Modem Router and Its Network
21
AC1200 WiFi VDSL/ADSL Modem Router Model D6220

Table of Contents

Other manuals for NETGEAR D6220

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR D6220 and is the answer not in the manual?

NETGEAR D6220 Specifications

General IconGeneral
DSL WAN-
Ethernet WANYes
SIM card slotNo
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)900 Mbit/s
Product typeTabletop router
Product colorBlack
Security algorithmsWPA, WPA2, WPA2-PSK
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11ac
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports5
Power source typeAC
Routing protocolsIP
Antennas quantity2
Cables includedLAN (RJ-45), Phone (RJ-11)
Weight and Dimensions IconWeight and Dimensions
Depth182 mm
Width240 mm
Height41 mm
Weight341 g
