Newport 1936-R series User Manual

15 Appendix E – Disassembly
Instructions
NOTE
These disassembly instructions are intended only for recycling at the end of the
product lifetime.
For troubleshooting or servicing, users should contact the local Newport Corporation
representative. There are no user serviceable parts inside the equipment.
Attempting to self-service the unit will void the warranty.
15.1 Disassembly instructions
Figure 72 shows an exploded version of the 1936-R/2936-R Series.
For recycling purposes, only, the disassembly steps are as follows:
1. Make sure the unit power cord is removed.
2. Remove any other cables: detectors, trigger cables, Analog Output
monitor cables, USB, RS232, and ground cable.
3. Remove the bottom screws of the cover.
4. Remove the cover.
5. Remove all the screws on the rear panel, except the fan screws.
6. Remove the rear panel.
7. Unplug PCBA 1 and 2 from the front panel.
8. Remove the screws that secure the front panel on enclosure.
9. Remove the front panel.
10. Remove the screws that secure PCBA 3 to the front panel.
11. Remove PCBA 3.
12. Remove the screws that secure PCBA 4 to the bottom of the
enclosure.
13. Remove PCBA 4.
