Safety Precautions 21
1.1.8 Fuses
Figure 8 Fuse Symbol
The fuse symbol in the figure above identifies the fuse location on the
Models 1936/2936 Series Optical Power Meters.
1.1.9 Frame or Chassis
Figure 9 Frame or Chassis Terminal Symbol
The symbol in the figure above appears on the 1936/2936 Series Optical
Power Meters. This symbol identifies the frame or chassis terminal
1.1.10 USB Connector Symbol
Figure 10 USB connector Symbol
The USB connector symbol in the above figure identifies the location of the
USB communications connector.
1.1.11 Waste Electrical and Electronic Equipment (WEEE)
Figure 11 WEEE Directive Symbol
This symbol on the product or on its packaging indicates that this product
must not be disposed of with regular waste. Instead, it is the user
responsibility to dispose of waste equipment according to the local laws. The
separate collection and recycling of the waste equipment at the time of
