Newport 1936-R series User Manual

30 General Information
Analog Output
Output Range
0
1
2
3
Full Scale Voltage
(Load > 100 kΩ)
1 V
2 V
5 V
10 V
Full Scale Voltage
(Load = 50 Ω)
0.5 V
1 V
2.5 V
-
Accuracy
1.0 %
1.0 %
1.0 %
1.0 %
Linearity
0.3%
0.3%
0.3%
0.3%
Trigger Level
Programmable Level
0…100 % Full Scale
Resolution
0.39 % Full Scale
1
With 5Hz filter on.
2
Listed signal ranges specify meter capability. Available signal ranges are detector dependent.
3
Maximum measurable signal is detector dependent.
4
While the maximum repetition range may equal the bandwidth, it really depends on the signal duty-cycle or the
signal shape.
5
The Maximum Repetition Rate refers to the meter pulse-by-pulse measuring capability. Due to its high
bandwidth, the 1936/2936 can take in signals with higher repetitive rates and outputs them undistorted at the
Analog Output.
6
The Temperature Range is detector dependent.
7
The Frequency Measurement min/max values are signal shape dependent. The specified frequency
measurement range and accuracy are defined for an amplitude of half full scale.
8
The instrument bandwidth is determined by the detector used. Please refer to Newport Corporation’s complete
offering on detector type. The specified bandwidth is measured from the instrument input (detector) to the Analog
Output BNC.
2.7 Unpacking and Handling
It is recommended that the Models 1936/2936 Series Optical Power Meters
be unpacked in a lab environment or work site. Unpack the system carefully;
small parts and cables are included with the instrument. Inspect the box
carefully for loose parts before disposing of the packaging. You are urged to
save the packaging material in case you need to ship your equipment in the
future.
2.8 Inspection for Damage
The Models 1936/2936 Series Optical Power Meters are carefully packaged
at the factory to minimize the possibility of damage during shipping. Inspect
the box for external signs of damage or mishandling. Inspect the contents for
damage. If there is visible damage to the instrument upon receipt, inform the
shipping company and Newport Corporation immediately.
