General Information 29
D.C. Voltage Measurement (Thermopile)
Signal Range
2,3
0
1
2
3
4
5
Full-Scale Voltage
2.5mV
25.0 mV
250 mV
2.50 V
25.0 V
130 V
Resolution
76.3 nV
763 nV
7.63 µV
76.3 µV
763 μV
3.96 mV
Accuracy
(Filtered)
1
0.3%
0.3%
0.3%
0.3%
0.3%
0.3%
Accuracy (Maximum
Measurement Rate=10kHz)
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
Frequency Measurement
(Square Wave Signal)
7
130 Hz –
200 kHz
20 Hz –
220 kHz
0.5 Hz –
220 kHz
0.5 Hz –
250 kHz
0.5 Hz – 220
kHz
0.5 Hz – 200
kHz
Frequency Measurement
(Sine Wave Signal)
7
130 Hz –
200 kHz
20 Hz –
220 kHz
20 Hz –
220 kHz
20 Hz –
220 kHz
20 Hz – 220
kHz
20 Hz – 200
kHz
Frequency Measurement
Accuracy
7
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
Bandwidth
8
640 kHz
1600 kHz
1600 kHz
1900 kHz
640 kHz
1900 kHz
Signal to Noise Ratio
1
(typ)
80dB
90dB
108dB
108dB
108dB
108dB
Pulse Voltage Measurement (Energy, Pyroelectric)
Signal Range
2,3
0
1
2
3
4
5
Full-Scale Current
2.5mV
25.0 mV
250 mV
2.50 V
25.0 V
130 V
Resolution
76.3 nV
763 nV
7.63 µV
76.3 µV
763 μV
3.96 mV
Accuracy
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
Frequency
Measurement
(Pulsed Signal)
7
130 Hz –
200 kHz
20 Hz –
220 kHz
0.5 Hz –
220 kHz
0.5 Hz –
250 kHz
0.5 Hz – 220
kHz
0.5 Hz – 200
kHz
Frequency
Measurement
Accuracy
7
1.0%
1.0%
1.0%
1.0%
1.0%
1.0%
Bandwidth
8
640 kHz
1600 kHz
1600 kHz
1900 kHz
640 kHz
1900 kHz
Maximum Pulse
Repetition Rate
5
10 kHz
10 kHz
10 kHz
10 kHz
10 kHz
10 kHz
RMS Measurement
Maximum Pulse Repetition Rate
2 kHz
10 kHz
Accuracy
1.0 %
2.0 %
