Communication Command Reference 87 87
Response Type Description
Error code, string Error code number and text for error code
as"text"per Appendix B, 0 if no errors
Related Commands: ERRors?
8.3.3.12 PM:ANALOGFILTER
Description Analog filter select command
Syntax PM:ANALOGFILTER value
Remarks The PM:ANALOGFILTER command selects the analog
filter setting.
Argument Value Analog Filter
Value 0 None
1 250 kHz
2 12.5 kHz
3 1 kHz
4 5 Hz
Related Commands: PM:ANALOGFILTER?
8.3.3.13 PM: ANALOGFILTER?
Description Analog filter query
Syntax PM:ANALOGFILTER?
Remarks The PM:ANALOGFILTER? query returns an integer
indicating the present analog filter setting.
Argument Value Analog Filter
Value 0 None
1 250 kHz
2 12.5 kHz
3 1 kHz
4 5 Hz
Related Commands: PM:ANALOGFILTER
8.3.3.14 PM:ANALOG:IMP
Description Analog output impedance select command
Syntax PM:ANALOG:IMP value
Remarks The PM:ANALOG:IMP command selects the analog
output impedance.
Argument Value Output Impedance
Value 0 50 Ω
1 100 kΩ
