7
03.2 VIEW OF CONNECTIONS
04. INSTALLATION OF OPTIONAL ACCESSORIES
04.1 PC AMPLIFIED SPEAKERS
04.2 PEN DRIVE
Figure 4.1.a
Figure 4.2.a
Figure 3.2.a
Figure 3.2.b
For the installation of the speakers, connect the standard plug
P2 on the audio input of the MG3000 [reference 9 in gure
3.1.a/gure 3.2.a].
IMPORTANT: The MG3000 does not supply power to the spe-
akers. The power supply must be made according to the speci-
cations of the manufacturer of the purchased product.
The ash drive must be inserted in the upper input, [reference 10 in
gure 3.1.a/gure 3.2.b].This accessory is used to perform Backup
and Restore of data contained in the internal EEPROM memory of
the MG3000, such as congurations, events and devices registered
in the system, and also to update the equipment’s rmware. Use
ash drive formatting as FAT16 or FAT32.
- ENGLISH -
210
