28
The message “Please wait...Automatic backup” is displayed, indicating that all
MG3000 data is being backed up to the internal SD CARD. The data contained
in this backup can be used for recovery, in case of damage to the internal me-
mory (EEPROM).
Access the “EDIT USER” programming menu, then select the type of device to
be edited and locate it by selecting the “UNIT” and “BUILDING” data of the user.
Is you select a valid unit and building value, e.g., one that is registered in the
database, all users’ data that are recorded for the same unit and building will be
loaded and could be listed by means of the arrows on the bottom of the screen.
In the example in [Figure 10.3a], there are 5 users registered in the “0000” of
building “A”.
Choose the user from his ID (name) and press the “PROCEED” key to access
the screen that will allow changing the device parameters. After changing, tap
“SAVE” to save.
10.3 EDIT USER
Figure 10.3.a
Figure 10.3.b
- ENGLISH -
231
