VBA23001-R.3762.A
- A37 ･ D90 -
・Mount the GND plate (#142) by fitting with the bosses.Mount the GND plate (#142) by fitting with the bosses.
・Mount the power drive PCB (#B1002) by fitting with the bosses. (Be careful not to pinch the wires.）Mount the power drive PCB (#B1002) by fitting with the bosses. (Be careful not to pinch the wires.））
Power drive PCB (#B1002)
GND plate (#142)
Power drive PCB unit
INC
