Nikon VBA23001 User Manual

VBA23001-R.3762 .A
- D29 ･ D90 -
・Peel off the sheet (#352).Peel off the sheet (#352).
・Remove the spring (#346) (carefully to avoid popping out of the spring) and the release button unit (#B350).Remove the spring (#346) (carefully to avoid popping out of the spring) and the release button unit (#B350).
・Take out the two screws (#602).Take out the two screws (#602).
・Remove the contact brush (#348) and the click spring (#347).Remove the contact brush (#348) and the click spring (#347).
Screw (#602)
×
2
Contact brush (#348)
Click spring (#347)
Sheet (#352)
Spring (#346)
Release button unit (#B350)
Power dial
INC
