Nikon VBA23001 User Manual

VBA23001-R.3762.A
- A93 ･ D90 -
・Attach the selector lock lever (#416).Attach the selector lock lever (#416).
・Attach the selector SW unit (#B420).Attach the selector SW unit (#B420).
・Tighten the screw (ROHS) (#707).Tighten the screw (ROHS) (#707).
・Attach the multi selector (#412).Attach the multi selector (#412).
・Attach the button (#414).Attach the button (#414).
・Attach the conducting rubber (#413).Attach the conducting rubber (#413).
Button / SW
Selector lock lever (#416)
Selector SW unit (#B420)
Screw (ROHS) (#707)
Conducting rubber (#413)
Button (#414)
Multi selector (#412)
・Attach the button (#421) by fitting with the bosses.Attach the button (#421) by fitting with the bosses.
・Attach the buttons (#429 and #430).Attach the buttons (#429 and #430).
Button (#421)
Button (#429)
Button (#430)
Grease: GN-20SB
INC
