VBA23001-R.3762.A
- A98 ･ D90 -
Screw (#670)
×6
Screw (#670)
×4
・Tighten the four screws (#670) and the six screws (#670) in numeric order as below.Tighten the four screws (#670) and the six screws (#670) in numeric order as below.
・Connect the connector.Connect the connector.
①
②
③
④
⑤
⑥
①
②
③
④
INC
