Oki Pro1040 User Manual

- 53 -
Table of Setting Items in the Control Panel Menu Screen
[Menus]

Unwinder Config
z
Shaded areas are factory-set values.
Item Value Description
Media Form Continuous Paper
Continuous Paper
(Black Mark)
Die-cut Label (Gap)
Die-cut Label (Black
Mark)
Continuous Label
Continuous Label
(Black Mark)
Specifies the shape of the roll paper.
Liner Width Config Liner Width
Mode
Auto
Custom
Specifies the mode for setting the width
of the label’s liner.
Auto:
The width of the liner is set given that
the label is in the center of the liner.
Custom:
The width of the liner is input and the
left gap is calculated given that the left
and right gaps are different.
Liner Width 29.4 millimeter
(1.16 inch)
～
105.6 millimeter
(4.16 inch)
109.0 millimeter
(4.29 inch)
～
130.0 millimeter
(5.12 inch)
Inputs the width of the liner.
Appears when the [Liner Width Mode] is
[Custom].
The initial values vary depending on your
operating environment.
Right Gap 2.0 millimeter
(0.08 inch)
～
25.4 millimeter
(1.00 inch)
Specifies the distance from the right edge
of the label to the right edge of the liner.
Paper Size A6
4x6 inch
Custom
Sets the size of the paper for the
unwinder.
The initial values vary depending on your
operating environment.
X Dimension 25.4 millimeter
(1.00 inch)
～
101.6 millimeter
(4.00 inch)
105.0 millimeter
(4.13 inch)
～
126.0 millimeter
(4.96 inch)
*1
Sets the width of the custom paper sizes
for the unwinder.
Sets the dimension perpendicular to the
paper feed direction.
The initial values vary depending on your
operating environment.
*1: 130.0 mm (5.12 inch) if the [Media Form] is [Continuous Paper] or [Continuous Paper (Black Mark)]
