Olivetti PR2 plus - Page 136

7-16 Service Manual
XZAC4219-05
5. Release the bush (4) of the shaft and remove the bracket (5) of the alignment pressure rollers, then remove the
entire assy (6).
Figure 7 - 19 Removing the roller pressure unit
6 Back off the six lock-screws (7) of the conveyor (8).
Figure 7 - 20 Feeder unit screws
5
4
6
7
8
7
7
8
