XZAC4219-05 Service Manual
5-5
O - X --
Photosensor test
failed
See the section “CALIBRATING
THE PHOTOSENSORS” on page 4
- 18 for an indication of the defective
photosensor.
O - X - X Magnetic reset
Replace the horizontal magnetic or
MICR interface card. See the
section “Horizontal magnetic/MICR
disassembly/reassembly” on page 7
- 28.
O - XX -
AFE scanner
error
• Perform calibration of the
scanner. See the section
“Calibrating the scanner” on
page 4 - 28.
• Replace the CIS. See the
sections: “CIS assy (upper
scanner) disassembly/
reassembly” on page 7 - 33 and
“CIS assy (lower scanner)
disassembly/reassembly” on
page 7 - 34.
OO X X X
Memory
Maintenance -
On the display (if
present) appears
the message
«WARNING
Maintenance
data».
Impossible to
recover valid
maintenance
data from the
dedicated Flash
EPROM area.
The maintenance
data will be
reinitialised with
the value «0».
• Press any key on the console to
display the next anomaly, when
necessary.
• Proceed with initialisation of the
printer.
OX - - - Service motor
See the section “Faults with
document handling” on page 5 - 19.
OX --X
Paper jammed
on insertion
photosensors
or photosensors
dirty
See the section “PROCEDURE
FOR CLEANING / REPLACING
THE PHOTOSENSORS” on page 6
- 2.
Console LED Anomalies Possible solution
ON Ready Station1 Local Station 2
