5-6 Service Manual
XZAC4219-05
OX - X -
FPGA scanner
error
• Perform calibration of the
scanner. See the section
“Calibrating the scanner” on
page 4 - 28.
• Replace the motherboard. See
the section Disassembling/
reassembling the motherboard
(printers with scanner).
OX O X X
HW Setup - On
the display (if
present) appears
the message
«WARNING
Setup
Hardware».
Inconsistency of
calibration values
(photosensors,
alignments etc).
All the calibration
values are
initialised with
their default
values.
• Press any key on the console to
display the next anomaly, when
necessary.
• Perform all the printer
calibrations. See the section
“PROGRAMMING AND
CALIBRATION” on page 4 - 1.
• Replace the motherboard. See
the section Disassembling/
reassembling the motherboard
(printers with scanner) or
Disassembling/reassembling
the motherboard (printers with
serial number 8.xxx.xxx and
1.xxx.xxx).
OX X - - Carriage motor
See the section “Faults during
writing of the document” on page 5 -
17.
OX X - X
Scanner STATIC
RAM error
Replace the motherboard. See the
section Disassembling/
reassembling the motherboard
(printers with scanner).
OX X X -
Scanner
DYNAMIC RAM
error
Replace the motherboard. See the
section Disassembling/
reassembling the motherboard
(printers with scanner).
OX - XX
Perform the
scanner
calibration - On
the display (if
present) the
message
appears «Make
SCANNER
Calibration».
• Press any key on the console to
display the next anomaly, when
necessary.
• Perform calibration of the
scanner. See the section
“Calibrating the scanner” on
page 4 - 28.
OO O - O
PTC power unit
not working
Replace the power unit. See the
section “Power supply unit
disassembly/reassembly” on page 7
- 26.
Console LED Anomalies Possible solution
ON Ready Station1 Local Station 2
