5 Creating Measurement Scenes
5 - 38
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
1 Select the Scene tab on the Edit flow screen.
A list of scenes is displayed. The current scene has a check mark.
2 Select a scene on the scene list to save and click [Save].
3 Select whether to save the scene data or to save the scene data and the registered images
together.
 Saving a scene data
“FileExplorer” is displayed.
1 Select a folder to save the scene data of the selected scene in the scene list.
Saving a scene
